Price:negotiable
Delivery time: 15-20 days after receiving deposit or LC.
Payment terms: TT/LC/DP
Application: Baby diaper,Adult diaper
Minimum order quanity: 1000.00 kgs
Packing details: Transparent wrapping film
High-quality breathable PE film backsheet for baby diapers. Soft, waterproof, and customizable with OEM & ODM logo printing. Factory-direct supply for global brands.
Breathable PE (polyethylene) film is a special microporous material designed to allow air and moisture to pass through while maintaining waterproofing. The following are its main features:
1. Moisture permeability (MVP)
Allow water vapor (sweat, moisture) to escape, reduce condensation, and maintain comfort.
Very suitable for hygiene products and agricultural applications that require airflow.
2. Waterproof and breathable
Block liquid water (rainwater, liquid), but allow steam transmission.
Used for diaper bottom film, sanitary napkin bottom film, etc
3. Micro porous structure
Containing micropores, it can achieve breathability.
The pores are small enough to prevent liquid infiltration but allow gas exchange.
4. Lightweight and flexible
Retaining the softness and flexibility of traditional PE films.
Suitable for disposable products such as diapers and sanitary napkins.
5. Environmental Protection Options
Some variants are recyclable or biodegradable (e.g. mixed with starch or PLA).
6. Application:
Medical supplies: surgical curtains, disposable surgical gowns.
Sanitary products: diapers, sanitary napkins.
Agriculture: greenhouse film, crop cover.
Packaging: Fresh agricultural products, meat trays (extended shelf life by reducing condensation).
|
Item |
Standard Value |
Values |
||
|
Min |
Max |
|||
|
Basic Weight (g/㎡) |
23±1.5 |
22.4 |
23.1 |
|
|
3-Dimensional Thicknes (mm) |
≥0.25 |
0.37 |
0.37 |
|
|
Fluid Penetrating Rate(%) |
100 |
100 |
100 |
|
|
Gloss (45°) |
≤8.0 |
3.9 |
4.3 |
|
|
Tensile Strenght |
MD Tensile |
≥4.0 |
6.5 |
7.56 |
|
CM Tensile |
≥2.0 |
3.1 |
3.9 |
|
|
Break Elongation rate (%) |
MD Tensile |
≥80 |
113 |
190 |
|
CM Tensile |
≥80 |
238 |
326 |
|
|
pH |
4.0-9.0 |
7.7 |
7.8 |
|
|
Width (mm) |
180±2 |
180 |
180 |
|
|
End side plane (even) limit |
Even |
0 |
0 |
|
|
Joint |
≤1 |
0 |
0 |
|
